This is an industrial-grade handheld Mobile device with high industrial-grade protection, professional drop test at a height of 1.5 meters, and the equipment is strong and reliable. The scanning engine matches freely to meet various scenarios. It can recognize barcodes such as fog, distortion, damage and distortion. It adopts dual PA and fast roaming to keep the device online at any time, delayed at zero hours, and does not drop the connection in complex network environments. It adopts the latest wireless chips and antenna gain technology to ultra-stable dual-band WIFI to ensure efficient data transmission.
Meet the needs of various scenarios
The structural design of the combination of soft and hard, professional dustproof and waterproof, solid and reliable equipment.
| Processor: Qualcomm SDM450 |
| Operating system: Android 9.0 Compact 10.0 |
| Storage: 32GB ROM+3GB RAM [optional 64GB+4GB] |
| Expansion slot: Micro SD slot |
| Display screen: 4.0 inch, resolution 800mm 480 |
| Touch screen: industrial capacitive screen |
| Camera: 8 million pixels, autofocus, support for PDAF |
| Keyboard backlight: White |
| Keyboard: power key / scan key / volume key / function key / number key |
| Microphone: single main microphone |
| Horn: 1.5W high power horn |
| Scan prompt: two-color scan prompt (red and green) / audio prompt |
| Scanning angle: tilt ±60 °, deflection ±60 °, rotation ±360 ° |
| G-SENSOR: supports 3 axes |
| Light source system: White light illumination, laser aiming |
| Battery: lithium battery, 5000m Ahpeng 3.8V |
| Battery hot swap: not supported |
| Charging: 2A quick charge, bottom 2pin charging terminal |
| Input and output: USB2.0 |
| OTG interface: support |
| Internal interface: 1 SIM card, 1 TF card |
| Electrostatic protection: ±15KV (air discharge) , ±8KV (contact discharge) |
| IP level: IP65 |
| Drop grade: 1.5 meters multiple cement falls |
| Size: 166.9 "73" 22.6 (mm) |
| Weight: 298g |
| Standard accessories: power adapter, USB cable, wristband |
| Optional accessories: single battery charger, whole machine charger, battery quadruple charger |
| Bluetooth: BT4.2 LE |
| GPS: supports GPS/AGPS/Glonass/ Beidou Target SNR ≥ 39dB (Signal level-130dBm) |
| NFC: 13.56MHz, within the readable range 3cm; protocol ISO14443A/14443B/15693 |
| WLAN: Wi-Fi 802.11a/b/g/n/r/ac (Dual-band Wi-Fi: 2.4G+5G) |
| China Netcom: GSM: 900/1800 MHz；WCDMA: B1/B5/B8；TDD-LTE: B38/B39/B40/B41；FDD-LTE: B1/B3/B5/B7/B8 |
| Scanning accuracy: 3mil |
| Rotate Angle of View: 360 |
| Charging tip: two-color light |
| Laser safety level: Class ll |
| Recognition speed: 20 times / S |
| Light sensor: not supported |
